"TrueLITE Model ELS" With ECO-mode operation providing up to 98.5% efficiency!

High Efficiency Three Phase Emergency Lighting Inverter!

Hello! Our "TrueLITE Model ELS" three phase centralized emergency lighting inverter offers several unique features and benefits! This LED-compatible inverter provides a high level of quality, performance, reliability, and energy savings that engineers, electrical distributors, and contractors are seeking in their emergency lighting projects. Available in 58.5 kW to 112.5 kW three phase sizes, the "Model ELS" features selectable ECO-mode operation providing up to 98.5% efficiency! This unique inverter offers four (4) field-selectable modes of operation based on input power conditions, lighting design, and the desire for high operating efficiency: On-Line Standby-On (ECO-Mode) Smart Active Standby-Off Full details about these modes are in both our product brochure and our general specifications!

Why Specify This Inverter? LED Inrush Compatible: Peak overload capability of 1200% to accommodate the inrush current from LED fixtures / drivers. Full Compliance With NFPA 101: Meets the NFPA 101 definition of a computer-based, self-testing / self-diagnostic emergency lighting system with data-logging.  Reliable Operation: Galvanic isolation and a robust design deliver reliable emergency power for critical life safety loads. Battery Care System: Deep discharge protection, current limitation, and voltage compensation based on ambient temperature are all features used to prolong battery life and reduce usage by different recharging methods.

Inverter shown without battery cabinet(s) and optional side cabinet for top cable entry. Four (4) battery cabinet configurations available, based on 90, 60, or 30 minute runtimes. Consult factory.

Input Source: High input power factor of 0.99, low input current distortion of ≤3%, and a "power walk-in" function that limits input current seen by the power source. High Efficiency: ECO-mode provides an efficiency rating of up to 98.5% without compromising critical features, diagnostics, and monitoring options. Digital Monitor: Wide graphic LCD display provides a close-up, detailed overview of the inverter status in real-time. Optional Seismic-Rated Models: Designed and tested in accordance with applicable portions of the ICC-AC156, ASCE 7-10, and IBC 2015 standards.

All Models Meet the Following: NFPA 101 and NFPA 111 standards as "Life Safety Equipment". UL 924 Listed as Emergency Lighting and Power Equipment, providing the required 90 minutes of emergency backup power. UL 924 Listed as Auxiliary Lighting and Power Equipment, providing alternate runtimes of 30, 60, and 120 minutes. C-UL Listed to CSA C22.2 No. 141-15 with 30, 60, or 90 minute runtimes.

For Critical Life Safety Applications Whether you are an Engineer specifying centralized battery backup for emergency lighting applications ... a Distributor or Contractor quoting a project that requires an emergency lighting inverter ... or and End User needing a reliable emergency lighting power source ... ... we invite you to visit our website! Read more about the "Model ELS"! While you're there, download our FREE General and Guide Specifications!
